Application
Suitable for CAT5E CAT6 Lan cables, CAT6A Lan cables.
Product Introduction
- High production capacity. Three-pitch principle design, when the back twist rate is 33%, the speed is 1.5 times that of ordinary twisted pair machines
- One machine for two purposes: Triple twisting and untwist twisting modes to meet higher quality wire twisting process
- Stable tension: The take-up tension remains constant from empty reel to full reel.
- Accurate twisting distance: Servo motor control, PLC directly sets the twisting distance value, error #2%
- Large wheel diameter. The take-up wheel and each wire guide wheel adopt a large wheel diameter design to reduce the bending radius of the wire and avoid damage to the twist length.
- Intelligent: The twisting length and the twist-off rate are controlled by PLC program, combined with the humanized touch screen operation screen, intelligent control
Application
Suitable for CAT5E CAT6 Lan cables, CAT6A Lan cables.
Product Introduction
- High production capacity. Three-pitch principle design, when the back twist rate is 33%, the speed is 1.5 times that of ordinary twisted pair machines
- One machine for two purposes: Triple twisting and untwist twisting modes to meet higher quality wire twisting process
- Stable tension: The take-up tension remains constant from empty reel to full reel.
- Accurate twisting distance: Servo motor control, PLC directly sets the twisting distance value, error #2%
- Large wheel diameter. The take-up wheel and each wire guide wheel adopt a large wheel diameter design to reduce the bending radius of the wire and avoid damage to the twist length.
- Intelligent: The twisting length and the twist-off rate are controlled by PLC program, combined with the humanized touch screen operation screen, intelligent control
Technical Parameters
| Model | PY-Φ500mm | PY-Φ630mm | |
|---|---|---|---|
|
Machine speed |
MAX1800RPM |
MAX1600RPM |
|
|
Lay range |
5-50 |
5-50 |
|
|
Back twist rate |
0-100% |
0-100% |
|
|
Take-up and pay-off reel |
Φ500 take-up, Φ500 pay-off |
Φ500 take-up, Φ500 pay-off |
|
|
Lay tolerance |
±2% |
±2% |
|
|
Formal structure |
split type |
Split type |
|
